TECHNICAL SPECIFICATIONS:

• Light source: 12 X 12W RGBWA UV 6in1 Led

• Power consumption: 150 W

• Size: 1050 x 80 x 165 mm

• Weight:4.3kg

• Lens: 42mm 30 degree (55 for option)

• Housing: Aluminium , black or white

• Cooling way: no fan,convection cooling,Temprature protection

• Dimming: 16bit digital dimming

• DMX Channel Modes:3/4/6/8/12/24/72/74CH

• Pixel : Dot (each color of led chip) controlled, segments controlled

• Operation modes: DMX-512 Protocol, Auto Run, Sound Active, Master/Slave,Static color,mult fixtures chasing automatically. WDMX （optional), RDM(optional)

• DMX512 connection: 3-pin XLR (5-pin for option)

• Power plugs: IEC or Neurtrik powercon, Seetronic True1, Neutrik True1

• Accessory: Flightcase, barndoor, frost filter

***Modifying the fixture according to your requirement is acceptable***
