TECHNICAL SPECIFICATIONS:

• Light source:36 pcs of 10W 5050 RGBWS(6 Leds x 6 segments) LED (S=warm white)

• Power: 400W

• IP Rate:IP65

• Illuminance(lx):Full on :82800 @ 1m,24400 @2m

• Color Temperature:  W:6000K,S:2500K

• LENS: 35mm,20°(12°&40° for option)

• Housing: Aluminum - Black or White

• Dimension: 372(Width)X186(Height)X110(Thickness)mm

• Weight: 8.1kg

• Cooling : Two Fans (3 speed levels),Temprature protection

•  DMX channels:  1 / 2 / 2 / 4W / 4S / 6 / 7 / 11 / 13 / 32ch

• 16bit digital dimming

• Operation modes: DMX-512 Protocol, Auto Running programs, Sound Active, Master/Slave,RDM(Optional), WDMX(Optional)

• PWM:1200HZ

• Strobe Effect: 1-25HZ

• Power connectors: Rean IP65 True 1

• DMX512 connection: 3-pin XLR or 5-pin XLR

• Accessory: extention DMX & Power cables(optional) , flightcase, Hanging Bar, independent Tool-free filter cover

• Rigging:

• (1)double yokes(can stand on the floor alone or hang up horizontally)

• (2)mounting point on the top and bottom for bracket to be hung vertically

• (3)cam locks for 1/4 turn Omega Bracket on the side and back

• (4)6 coffinlocks +3 tool free lock handles for multi-fixtures linking and hanging horizontally and vertically;

• Certificate:CE,ROHS

***Modifying the fixture according to your requirement is acceptable***
